Manufacturer: Lunati
SKU: 21760710
Voodoo Camshafts for Harley Davidson applications deliver more area under the curve than any other series of cams for these engines. This means more throttle response, quicker acceleration, more vacuum and better efficiency. These factors, combined with maximum horsepower and torque, make Voodoo Camshafts the perfect choice for your Harley..Not legal for use on pollution controlled vehicles, check local laws before installation. NOT legal for sale in California Strong mid range power for 88-95 c.i. engines. Works well with compression ratios of up to 10:1..Valve Lift (in): 0.569.Intake Duration at .053 (degrees): 239.Exhaust Duration at .053 (degrees): 243.Grind Lobe Sep: 105.Intake Centerline (degrees): 101.Exhaust Centerline (degrees): 109.Intake Opening at .053 (degrees): 19.Intake Closing at .053 (degrees): 41.Exhaust Opening at .053 (degrees): 51.Exhaust Closing at .053 (degrees): 13.Intake Lift at TDC (in): 0.189.Exhaust Lift at TDC (in): 0.154
| Weight | 1 kg |
| SKU | 21760710 |
| Name | Voodoo Chain Drive Cam - 0.569 Lift - 1700-5700 RPM Range |
| Description |
Voodoo Chain Drive Cam - 0.569 Lift - 1700-5700 RPM RangeManufacturer: Lunati SKU: 21760710 Voodoo Camshafts for Harley Davidson applications deliver more area under the curve than any other series of cams for these engines. This means more throttle response, quicker acceleration, more vacuum and better efficiency. These factors, combined with maximum horsepower and torque, make Voodoo Camshafts the perfect choice for your Harley..Not legal for use on pollution controlled vehicles, check local laws before installation. NOT legal for sale in California Strong mid range power for 88-95 c.i. engines. Works well with compression ratios of up to 10:1..Valve Lift (in): 0.569.Intake Duration at .053 (degrees): 239.Exhaust Duration at .053 (degrees): 243.Grind Lobe Sep: 105.Intake Centerline (degrees): 101.Exhaust Centerline (degrees): 109.Intake Opening at .053 (degrees): 19.Intake Closing at .053 (degrees): 41.Exhaust Opening at .053 (degrees): 51.Exhaust Closing at .053 (degrees): 13.Intake Lift at TDC (in): 0.189.Exhaust Lift at TDC (in): 0.154
|
| Brand | Braking |
Make: Harley Davidson
Model: FLSTC Heritage Softail Classic
Years: 2007 - 2017
View All Parts for This VehicleMake: Harley Davidson
Model: FLSTN Softail Deluxe
Years: 2007 - 2017
View All Parts for This VehicleMake: Harley Davidson
Model: FXDL Low Rider
Years: 2014, 2015, 2016, 2017
View All Parts for This VehicleMake: Harley Davidson
Model: FXDWG Dyna Wide Glide
Years: 2007 - 2017
View All Parts for This VehicleMake: Harley Davidson
Model: FLHTCU Electra Glide Ultra Classic
Years: 2007 - 2016
View All Parts for This VehicleMake: Harley Davidson
Model: FLHTCUL Electra Glide Ultra Classic Low
Years: 2015, 2016
View All Parts for This VehicleMake: Harley Davidson
Model: FLHTCUTG Tri Glide Ultra
Years: 2014, 2015, 2016
View All Parts for This VehicleMake: Harley Davidson
Model: FLHTKL Ultra Limited Low
Years: 2015, 2016
View All Parts for This VehicleMake: Harley Davidson
Model: FLTRU Road Glide Ultra
Years: 2011, 2012, 2013, 2016
View All Parts for This VehicleMake: Harley Davidson
Model: FLTRXS Road Glide Special
Years: 2015, 2016
View All Parts for This VehicleMake: Harley Davidson
Model: FLHTK Electra Glide Ultra Limited
Years: 2010, 2011, 2012, 2013, 2014
View All Parts for This VehicleMake: Harley Davidson
Model: FXDC Super Glide Custom
Years: 2007 - 2014
View All Parts for This VehicleMake: Harley Davidson
Model: FLHRC Road King Classic
Years: 2007 - 2013
View All Parts for This VehicleMake: Harley Davidson
Model: FLHTC Electra Glide Classic
Years: 2007 - 2013
View All Parts for This VehicleMake: Harley Davidson
Model: FLHTCUTG Tri Glide Ultra Classic
Years: 2009, 2010, 2011, 2012, 2013
View All Parts for This VehicleMake: Harley Davidson
Model: FLTRX Road Glide Custom
Years: 2010, 2011, 2012, 2013
View All Parts for This VehicleMake: Harley Davidson
Model: FLSTSB Cross Bones
Years: 2008, 2009, 2010, 2011
View All Parts for This VehicleMake: Harley Davidson
Model: FXD Dyna Super Glide
Years: 2007, 2008, 2009, 2010
View All Parts for This VehicleMake: Harley Davidson
Model: FXSTC Softail Custom
Years: 2007, 2008, 2009, 2010
View All Parts for This VehicleMake: Harley Davidson
Model: FLHT Electra Glide Standard
Years: 2007, 2008, 2009
View All Parts for This VehicleMake: Harley Davidson
Model: FLTR Road Glide
Years: 2007, 2008, 2009
View All Parts for This VehicleMake: Harley Davidson
Model: FXDL Dyna Low Rider
Years: 2007, 2008, 2009
View All Parts for This VehicleMake: Harley Davidson
Model: FXSTB Night Train
Years: 2007, 2008, 2009
View All Parts for This VehicleMake: Harley Davidson
Model: FLSTSC Softail Springer Classic
Years: 2007
View All Parts for This VehicleNo reviews yet. Be the first to review this product!
